Online Infrared Sensors with Digital Display
Compact multi-channel infrared sensing with intelligent digital electronics, LCD display, flexible outputs, and industrial protection options.
A compact, intelligent multi-channel infrared sensing architecture consisting of a miniature stainless steel optical sensing head connected to intelligent digital communication electronics with an integrated LCD display.
Key Technical Features
Temperature Range: -40 °C to 1800 °C.
Optical Resolution: Up to 100:1.
Signal Processing: Adjustable emissivity, peak hold, valley hold, and averaging functions.
Response Time: 10 mSec.
Digital Interface: USB 2.0; RS485, Modbus, or Profibus optional.
Outputs: Scalable 4–20 mA, 0–20 mA, 0–10 V, 0–5 V, thermocouple J/K/R/S, and 0–5 V head ambient output.
Spectral Response: 1M 1 μm and 2M 1.6 μm ranges for high-temperature metals, clean targets, medium-temperature metals, and alloys.
Tailored Protection: Custom accessories, monitoring/data-logging software, SS316 water-cooling jackets and air-purge collars, and high-temperature/flameproof cables.
Non-contact infrared measurement from -40 ºC to 1800 ºC with up to 100:1 optical resolution.
Adjustable emissivity, peak hold, valley hold, and averaging functions for stable measurements.
USB 2.0 with optional RS485, Modbus, Profibus and scalable analog outputs.
SS316 cooling jackets, air-purge collars, customized software, and high-temperature/flameproof cables.
